WHISPERKOOL 3500tiR Ducted Wine Cellar Cooling Unit – Up to 800 ft³

Engineered with over-sized coils and powerful ventilation system the WhisperKOOL® Extreme Series is designed to vent to the outside in hot and cold ambient climates. This fully-ducted unit can operate up to 25 ducted feet away (creating a noise-free wine cellar) in 110°F conditions and maintain a 55°F temperature differential between the wine cellar and the exhaust environment (interior or exterior).

The Extreme Series 3500tiR Ducted model has a cooling capacity of 800 cubic feet.

• Fully Ducted / Stand Alone
• Cooling Capacity of 800 ft3
• 14.25″W x 22.5″H x 27.5″D
• 115 lbs
• 110v/60Hz dedicated circuit breaker required
• No licensed HVAC professional required
• Drain line is required
• Can vent to outdoors
• Max differential between cellar & exhaust 55°F
• Maximum outdoor temperature of 110°F
• Remote sensor option
• Digital interface
• Power cord

More information from WhisperKOOL Extreme Series

Download the WHISPERKOOL 3500tiR Ducted Cooling Unit Owner Manual.

Download the WHISPERKOOL 3500tiR Ducted Cooling Unit Owner Manual (W/ 24V Thermostat).

The WHISPERKOOL 3500tiR Ducted is a ducted, split-system wine cellar cooling unit: the compressor and condenser install remotely while a ducted evaporator distributes conditioned air evenly through supply and return ductwork. This split-system wine cooler configuration is well suited to larger or architecturally complex wine rooms up to 800 ft³, where a self-contained wine cooling unit isn't practical, since the noisiest components sit outside the tasting or storage space entirely. As a dedicated ducted wine cellar cooling unit, it gives builders and collectors a flexible way to hold precise temperature and humidity across a demanding cellar design.
